Al-Bronze 3-Pcs Floating Ball Valve - High Quality

Nominal diameter: 1/2"
Pressure rating: ANSI Class 200#,
Connection: threaded Female NPT as per ASME B1.20.1
Body material: ASTM B148 C95800 Ni-Al bronze
Operation: lever
Features: 3-piece body, floating ball, bolted bonnet

Introducing our latest addition to the product line, the 1/2 Nominal diameter ball valve with an ANSI Class 200# pressure rating. This high-performance valve features a threaded female NPT connection as per ASME B1.20.1 standards, making installation a breeze. Crafted from ASTM B148 C95800 Ni-Al bronze, this valve is built to last and withstand even the harshest conditions. Its 3-piece body, floating ball, and bolted bonnet design ensure smooth operation and easy maintenance. Equipped with a user-friendly lever for seamless control, this ball valve is a reliable solution for various industrial applications. Plus, our company name is proudly displayed on the valve, promising unwavering quality and performance. Upgrade your system with our top-of-the-line ball valve for unparalleled durability and efficiency

    Detail introduction

    Bolted bonnet, three-piece body, floating Ball
    Full or reduced bore, blowout proof stem
    Fire safe and Anti static, Stainless steel ball

    Standards compliance

    Design and Manufacture: API 608, ASME B16.34, BS 5351
    Face to face(end to end): ANSI B16.10, API 6D
    Flanged connection: 1/2"~24" according to ANSI B16.5
    Fire-safe: API 607, API 6FA
    Butt welded end: ANSI B16.25
    Test and inspection: API 598, API 6D
