01
API 6D lever operated floating ball valve.jpg

API 6D Lever Operated Floating Ball Valve

Nominal diameter: 3"
Pressure rating: ANSI Class 600#,
Connection: RF flanged as per ASME B16.5
Body material: ASTM A216 WCB
Operation: lever
Features: 2-piece body, cast steel body, floating ball, bolted bonnet

Introducing our 3 Nominal Diameter ANSI Class 600# ball valve, featuring RF flanged connection as per ASME B16.5 standards. Constructed with ASTM A216 WCB cast steel, this valve is designed for durability and high pressure applications. The 2-piece body, floating ball, and bolted bonnet ensure reliable performance, while the lever operation allows for easy manual control. This product is ideal for various industrial uses, providing a secure and efficient shut-off solution. Trust our company name for quality and precision engineering in every valve we produce

    Contact us
    product details
    Product parameter

    Detail introduction

    Bolted bonnet, two-piece body, floating Ball
    Full or reduced bore, blowout proof stem
    Fire safe and Anti static, Stainless steel ball
    ASTM A216 WCB,A351 CF8,A351 CF8M, A351 CF3,A351 CF3M,A351 CN7M

    Standards compliance

    Design and Manufacture: API 608, API 6D, BS 5351
    Face to face(end to end): ANSI B16.10, API 6D
    Flanged connection: 2"~24" according to ANSI B16.5
    Fire-safe: API 607, API 6FA
    Butt welded end: ANSI B16.25
    Test and inspection: API 598, API 6D

    Main parts and material list

    Materials
    NO. Part Name Material
    13 Handle Carbon steel
    12 Lock Nut Carbon steel
    11 Gland Nut Carbon steel
    10 Thrust Washer PTFE/NYLON
    9 Gland Bush Stainless steel
    8 Stem Stainless steel
    NO. Part Name WCB LCB
    7 Stud And Nut A193 Gr B7/A194 Gr 2H A320 Gr L7/A194 Gr 4
    6 Packing Graphite/PTFE Graphite/PTFE
    5 Ball Seat PTFE/RPTFE/NYLON SPTFE/RPTFE/NYLON
    4 Gasket Grafoil/spiral wound Grafoil/spiral wound
    3 Ball A182 F6a A182 F304
    2 R-Body A216 Gr WCB A352 Gr LCB
    1 L-Body A216 Gr WCB A352 Gr LCB
    NO. Part Name CF8 CF8M
    7 Stud And Nut A193 Gr B16/A194 Gr 4/7 A193 Gr B7/A194 Gr 2H
    6 Packing Graphite/PTFE Graphite/PTFE
    5 Ball Seat PTFE/RPTFE/NYLON PTFE/RPTFE/NYLON
    4 Gasket Grafoil/spiral wound Grafoil/spiral wound
    3 Ball A182 F304 A182 F316
    2 R-Body A351 Gr CF8 A351 Gr CF8M
    1 L-Body A351 Gr CF8 A351 Gr CF8M

    Dimensions (mm) and weight for ANSI Class 150

    Size inch January 2nd March 4th 1 2001/1/2 2 2002/1/2 3 4 6 8
    L-RF mm 108 117 127 165 178 191 203 229 394 457
    L1-BW mm 140 152 165 190 216 241 283 305 457 521
    L2-RTJ mm - - 140 178 191 203 216 241 406 470
    H mm 65 70 80 95 110 135 145 170 235 275
    W mm 150 155 160 180 200 225 325 350 500 600
    Weight Kg 3 4 5 8 12 21 26 43 80 155

    Dimensions (mm) and weight for ANSI Class 300

    Size inch January 2nd March 4th 1 2001/1/2 2 2002/1/2 3 4 6 8
    L-RF mm 140 152 165 190 216 241 283 305 403 502
    L1-BW mm 140 152 165 191 216 241 283 305 457 521
    L2-RTJ mm 151 165 178 203 232 257 298 321 419 518
    H mm 70 85 90 105 120 145 160 195 250 290
    W mm 155 160 180 200 225 325 350 500 600 700
    Weight Kg 3 5 7 13 15 28 32 55 105 170
