Forged Steel Floating Ball Valve With Nipples
Standard compliance
Bolted bonnet, three-piece body, floating Ball
Full or reduced bore, blowout proof stem
Fire safe and Anti static, Stainless steel ball, class 150~class 2500
Specifications
Size 1” up to 10“(DN 15 up to DN 250)
1/2" to 10" – 150#
1/2" to 8" – 300#
1/2" to 4" – 600#
1/2" to 1-1/2" – 900#, 1500# & 2500#
Pressure Rating: ASME 150# to 2500#
Materials: Carbon Steel, Low Temperature Carbon Steel, Stainless Steel, Duplex Stainless Steel, Super Duplex Stainless Steel, Nickel Alloys, Nickel Aluminum Bronze, Hastelloy, Inconel Etc.
Seating: Soft Seated (PTFE/RPTFE /PEEK/NYLON/DEVLON) and Metal Seated
End Connection: Flanged RF/RTJ, BW, FNPT & SW Ends
Operator / Actuator: Lever, Gear, Actuator (Pneumatic, Hydraulic, Motorised, Electro-Hydraulic)
Specification & Standards
Design – ASME B16.34/BS5351
Face to Face – ASME B16.10
End Flange – ASME B16.5
BW End – ASME B16.25
Test – API598/API6D
Fire Safe Test – API607/API6FA
Special – NACE MR-01-75
Features
One Piece, Two Piece, Three Piece, Fully Welded
Anti- Static Device
Blow- Out Proof Stem
Fire Safe Design
Low Emission
