Lever Operated Trunnion Mounted Ball Valve

Introducing our high-quality 4 ANSI Class 600# RF flanged ball valve, designed for superior performance and durability. This ball valve features a 2-piece cast steel body with a floating ball and bolted bonnet, providing reliability and ease of maintenance. With a nominal diameter of 4 and a pressure rating of ANSI Class 600#, this valve is suitable for a wide range of industrial applications. The lever operation allows for smooth and precise control, making it a versatile choice for various uses. Manufactured with ASTM A216 WCB material, our ball valve is built to withstand high-pressure environments, ensuring long-lasting performance. Trust in our company name for quality assurance and exceptional customer service. Elevate your operations with our dependable and efficient ball valve

product details

Product parameter

Detail introduction

Bolted bonnet, two-piece body, floating Ball

Full or reduced bore, blowout proof stem

Fire safe and Anti static, Stainless steel ball

ASTM A216 WCB,A351 CF8,A351 CF8M, A351 CF3,A351 CF3M,A351 CN7M

Standards compliance

Design and Manufacture: API 608, API 6D, BS 5351

Face to face(end to end): ANSI B16.10, API 6D

Flanged connection: 2"~24" according to ANSI B16.5

Fire-safe: API 607, API 6FA

Butt welded end: ANSI B16.25

Test and inspection: API 598, API 6D

Main parts and material list

Materials
NO.	Part Name	Material
13	Handle	Carbon steel
12	Lock Nut	Carbon steel
11	Gland Nut	Carbon steel
10	Thrust Washer	PTFE/NYLON
9	Gland Bush	Stainless steel
8	Stem	Stainless steel

NO.	Part Name	WCB	LCB
7	Stud And Nut	A193 Gr B7/A194 Gr 2H	A320 Gr L7/A194 Gr 4
6	Packing	Graphite/PTFE	Graphite/PTFE
5	Ball Seat	PTFE/RPTFE/NYLON	SPTFE/RPTFE/NYLON
4	Gasket	Grafoil/spiral wound	Grafoil/spiral wound
3	Ball	A182 F6a	A182 F304
2	R-Body	A216 Gr WCB	A352 Gr LCB
1	L-Body	A216 Gr WCB	A352 Gr LCB

NO.	Part Name	CF8	CF8M
7	Stud And Nut	A193 Gr B16/A194 Gr 4/7	A193 Gr B7/A194 Gr 2H
6	Packing	Graphite/PTFE	Graphite/PTFE
5	Ball Seat	PTFE/RPTFE/NYLON	PTFE/RPTFE/NYLON
4	Gasket	Grafoil/spiral wound	Grafoil/spiral wound
3	Ball	A182 F304	A182 F316
2	R-Body	A351 Gr CF8	A351 Gr CF8M
1	L-Body	A351 Gr CF8	A351 Gr CF8M

Dimensions (mm) and weight for ANSI Class 150

Size	inch	1月2日	3月4日	1	2001/1/2	2	2002/1/2	3	4	6	8
L-RF	mm	108	117	127	165	178	191	203	229	394	457
L1-BW	mm	140	152	165	190	216	241	283	305	457	521
L2-RTJ	mm	-	-	140	178	191	203	216	241	406	470
H	mm	65	70	80	95	110	135	145	170	235	275
W	mm	150	155	160	180	200	225	325	350	500	600
Weight	Kg	3	4	5	8	12	21	26	43	80	155

Dimensions (mm) and weight for ANSI Class 300

Size	inch	1月2日	3月4日	1	2001/1/2	2	2002/1/2	3	4	6	8
L-RF	mm	140	152	165	190	216	241	283	305	403	502
L1-BW	mm	140	152	165	191	216	241	283	305	457	521
L2-RTJ	mm	151	165	178	203	232	257	298	321	419	518
H	mm	70	85	90	105	120	145	160	195	250	290
W	mm	155	160	180	200	225	325	350	500	600	700
Weight	Kg	3	5	7	13	15	28	32	55	105	170
