Reduced Bore Trunnion Mounted Ball Valve

Nominal diameter: 10"x8"
Pressure rating: ANSI Class 600#
Connection: RF flanged as per ANSI B16.5
Body material: ASTM A352 LCC, Ball: A182 F316, Shaft: A182 F316, Seat ring: RPTFE
Operation: worm-gear
Features: two piece bolted body design, reduced bore, low temperature carbon steel

Introducing our 10x8 ANSI Class 600# RF flanged ball valve, designed and manufactured with precision using high-quality materials. The body is constructed from ASTM A352 LCC, while the ball and shaft are made from A182 F316, ensuring durability and corrosion resistance. The seat ring is crafted from RPTFE for reliable sealing. With a two piece bolted body design, reduced bore, and low temperature carbon steel, this valve is ideal for a wide range of industrial applications. Its worm-gear operation allows for smooth and precise control of flow. Our product guarantees superior performance and longevity, meeting the highest industry standards. Trust in our company name for quality and reliability in your valve solutions

product details

Product parameter

Detail introduction

Bolted cover, Two-piece or three-piece body, fixed Ball

Full or Reduced bore, Blowout Proof Stem, Fire safe and Anti static

Dual seat with injection and drain & outlet

ASTM A216 WCB,A351 CF8, A351 CF8M, A351 CF3,A351 CF3M,A351 CN7M

Standards compliance

Design and Manufacture: API 6D

Face to face(end to end): API 6D

Flanged connection: 2"~24" to ANSI B16.5; Butt welded end: ANSI B16.25

Fire-safe: API 607, API 6FA

Test and inspection: API 6D, API 598

Main parts and material list

Materials
NO.	Part Name	Material
21	Drain Plug	Carbon steel/stainless steel
20	Worm Gear/Actuator	Manufacturer??s standard
19	Antistatic Device	Stainless steel
18	Constant Spring	17-7PH/inconel-Alloy
17	O-Ring	Viton
16	Ball Guide Bush	Carbon steel/SS
15	Cover Washer	PTFE/NYLON
14	Thrust Washer	Graphite PTFE/NYLON
13	Stem	CS+Plated/stainless steel

NO.	Part Name	WCB	LCB
12	Socket Head Screw	A193 Gr B7	A320 Gr L7
11	Stud and Nut	A193 Gr B7/A194 Gr 2H	A320 Gr L7/A194 Gr 4
10	Gasket	PTFE/SPIRAL WOUND	PTFE/SPIRAL WOUND
9	Packing	PTFE/Graphite	Graphite/PTFE
8	Seat Ring	PTFE/RPTFE	PTFE/RPTFE
7	Sealing Plate	A216 Gr WCB	A352 Gr LCB
6	Stem Retainer	A216 Gr WCB	A352 Gr LCb
5	Ball Guide	A105N+ENP	A182 F304
4	Ball Seat	A182 F304	A182 F304
3	Ball	A182 F6a	A182 F304
2	R-Body	A216 Gr WCB	A352 Gr LCB
1	L-Body	A216 Gr WCB	A352 Gr LCB

NO.	Part Name	CF8	CF8M
12	Socket Head Screw	A193 Gr B8	A193 Gr B8
11	Stud And Nut	A193 B8/A194 8	A320 B8M/A194 B8
10	Gasket	PTFE/SPIRAL WOUND	PTFE/SPIRAL WOUND
9	Packing	GRAFOIL	GRAFOIL
8	Ball Seat	PTFE/RPTFE	PTFE/RPTFE
7	Sealing Plate	A315 Gr CF8	A315 Gr CF8M
6	Stem Retainer	A315 Gr CF8	A315 Gr CF8M
5	Ball Guide	A315 Gr CF8	A315 Gr CF8M
4	Seat Ring	A182 F304	A182 F316
3	Ball	A315 Gr CF8	A315 Gr CF8M
2	R-Body	A315 Gr CF8	A315 Gr CF8M
1	L-Body	A315 Gr CF8	A315 Gr CF8M

Dimensions (mm) and weight for ANSI Class 150

Size		inch	2	3	4	6	8	10	12	14	16	18	20	22	24	28	32	36	40
L	RF	mm	178	203	229	394	457	533	610	686	762	864	914	991	1067	1245	1372	1524	1753
L	BW	mm	216	283	305	457	521	559	635	762	838	914	991	1092	1143	1346	1524	1727	1956
H1			100	125	150	210	260	305	350	395	445	480	530	600	640	710	790	1040	1080
H			125	150	315	385	440	485	555	635	690	740	775	930	1000	1095	1175	1280	1350
W			250	400	600	600	600	600	800	800	800	800	800	800	800	800	800	800	800
WEIGHT(KG)			12	22	35	74	205	322	460	576	864	1280	1600	2450	3340	4500	5940	7540	9320

Dimensions (mm) and weight for ANSI Class 300

Size		inch	2	3	4	6	8	10	12	14	16	18	20	22	24	28	32	36	40
L	RF	mm	178	283	305	403	502	568	648	762	838	914	991	1092	1143	1346	1524	1727	1956
L	BW	mm	216	283	305	457	521	559	635	762	838	914	991	1092	1143	1346	1524	1727	1956
H1			100	125	150	210	260	305	350	395	445	480	530	600	640	710	790	1040	1080
H			125	150	315	385	440	485	555	635	690	740	775	930	1000	1095	1175	1280	1350
W			250	400	600	1100	600	600	800	800	800	800	800	800	800	800	800	800	800
WEIGHT(KG)			25	35	50	118	255	370	533	640	1030	1542	2100	2960	4200	5300	7860	8684	10300

Dimensions (mm) and weight for ANSI Class 600

Size		Inch	2	3	4	6	8	10	12	14	16	18	20	24	28	30	32	36
L	RF	mm	292	356	432	559	660	787	838	889	991	1092	1194	1397	1549	1651	1778	2083
	BW	mm	295	359	435	562	664	791	841	892	994	1095	1200	1407	1549	1651	1778	2083
	RTJ	mm	292	356	432	559	660	787	838	889	991	1092	1194	1397	1549	1651	1778	2083
H1			115	140	170	230	295	330	400	445	490	520	570	700	770	850	905	1150
H			140	170	340	410	480	530	600	620	720	780	875	1000	1180	1200	1270	1400
W			400	600	600	600	600	800	800	800	800	800	800	800	800	800	800	800
WEIGHT(KG)			35	65	108	170	300	615	820	1050	1490	2050	2650	5300	7600	9800	11500	16000

Dimensions (mm) and weight for ANSI Class 900

Size		inch	1	2001/1/4	2001/1/2	2	3	4	6	8	10	12	14	16	20	24
L	RF&BW	mm	254	279	305	368	381	457	610	737	838	965	1029	1130	1334	1569
L	RTJ	mm	254	279	305	371	384	460	613	740	841	968	1038	1140	1334	1569
H1			80	85	95	115	150	165	230	295	330	400	420	500	580	720
H			120	145	160	160	180	350	430	500	550	630	660	750	890	1020
W			250	250	400	600	600	600	600	800	800	800	800	800	800	800
WEIGHT(KG)			21	28	40	50	80	170	390	640	970	1210	1560	2240	4200	6800

Dimensions (mm) and weight for ANSI Class 1500

Size		inch	1	2001/1/4	2001/1/2	2	3	4	6	8	10	12	14	16	20
L	RF&BW	mm	254	279	305	368	470	546	705	832	991	965	1276	1407	1686
L	RTJ	mm	254	279	305	371	473	549	711	841	1000	968	1276	1407	1686
H1			80	85	95	115	150	170	230	295	330	400	420	500	580
H			120	145	160	160	180	350	430	500	550	630	660	750	890
W			250	250	400	600	600	600	600	800	800	800	800	800	800
WEIGHT(KG)			21	28	40	55	105	205	525	880	1560	2355	2980	4070	9075
